Name: PLSS BLM Section

Display Field: T_S_R

Type: Feature Layer

Geometry Type: esriGeometryPolygon

Description: PLSS BLM SECTIONSThis dataset represents the GIS Version of the Public Land Survey System including both rectangular and non-rectangular surveys. The primary source for the data is cadastral survey records housed by the BLM supplemented with local records and geographic control coordinates from states, counties as well as other federal agencies such as the USGS and USFS. The data has been converted from source documents to digital form and transferred into a GIS format that is compliant with FGDC Cadastral Data Content Standards and Guidelines for publication. This data is optimized for data publication and sharing rather than for specific 'production' or operation and maintenance.This data set includes the following: PLSS Fully Intersected (all of the PLSS feature at the atomic or smallest polygon level), PLSS Townships, First Divisions and Second Divisions (the hierarchical break down of the PLSS Rectangular surveys), and the Bureau of Census 2015 Cartographic State Boundaries. The Entity-Attribute section of this metadata describes these components in greater detail. Please note that the data on this site, although published at regular intervals, may not be the most current PLSS data that is available from the BLM. Updates to the PLSS data at the BLM State Offices may have occurred since this data was published.To ensure users have the most current data, please refer to the links provided in the PLSS CadNSDI Data Set Availability accessible here:https://gis.blm.gov/EGISDownload/Docs/PLSS_CadNSDI_Data_Set_Availability.pdfor contact the BLM PLSS Data Set Manager.https://data-ladotd.opendata.arcgis.com/search?collection=Dataset

Service Item Id: 2b62ef60f6054f3b938bfeea29290f92

Copyright Text: ©2025 James E. "Jim" Mitchell, Louisiana Department of Transportation & Development Office of Technology Services, jim.mitchell@la.gov Last Updated: 03/2021

Default Visibility: true

MaxRecordCount: 2000

MaxSelectionCount: 2000

Supported Query Formats: JSON, geoJSON, PBF

Min Scale: 0.0

Max Scale: 0.0

Supports Advanced Queries: true

Supports Statistics: true

Has Labels: false

Can Modify Layer: true

Can Scale Symbols: false

Use Standardized Queries: true

Supports Datum Transformation: true

Extent:

XMin: 3615893.558202639
YMin: 603647.2449207306
XMax: 3851273.8669686317
YMax: 810121.7033620626
Spatial Reference: 102682  (3452)  LatestVCSWkid(0)

Drawing Info:

Renderer:
Simple Renderer:
Symbol:
Style: esriSFSSolid
Color: [214, 246, 252, 0]
Outline:
Style: esriSLSSolid
Color: [0, 0, 0, 255]
Width: 0
Label: N/A
Description: N/A
Transparency: 0
Labeling Info:

Feature Draw Order:

N/A

Advanced Query Capabilities:

Supports Statistics: true
Supports OrderBy: true
Supports Distinct: true
Supports Pagination: true
Supports TrueCurve: true
Supports Returning Query Extent: true
Supports Query With Distance: true
Supports Sql Expression: true
Supports Query With ResultType: false
Supports Returning Geometry Centroid: false
Supports Binning LOD: false
Supports Query With LOD Spatial Reference: false
Supports Percentile Statistics: true
Supports Having Clause: true
Supports Count Distinct: true
Supports Time Relation: true
Supports Sql Format: false
Supports Query Analytic: true
Supports Query With Current User: true

HasZ: false

HasM: false

Has Attachments: false

HTML Popup Type: esriServerHTMLPopupTypeAsHTMLText

Type ID Field: null

Fields:

• OBJECTID ( type: esriFieldTypeOID, alias: OBJECTID )
• section_ ( type: esriFieldTypeInteger, alias: section_ )
• township ( type: esriFieldTypeInteger, alias: township )
• range ( type: esriFieldTypeInteger, alias: range )
• TR ( type: esriFieldTypeString, alias: TR, length: 10 )
• T_S_R ( type: esriFieldTypeString, alias: T_S_R, length: 50 )
• Shape ( type: esriFieldTypeGeometry, alias: Shape )
• Shape.STArea() ( type: esriFieldTypeDouble, alias: Shape.STArea() )
• Shape.STLength() ( type: esriFieldTypeDouble, alias: Shape.STLength() )
• GlobalID ( type: esriFieldTypeGlobalID, alias: GlobalID, length: 38 )
• created_user ( type: esriFieldTypeString, alias: created_user, length: 255 )
• created_date ( type: esriFieldTypeDate, alias: created_date, length: 8 )
• last_edited_user ( type: esriFieldTypeString, alias: last_edited_user, length: 255 )
• last_edited_date ( type: esriFieldTypeDate, alias: last_edited_date, length: 8 )

Supported Operations:   Query   Query Attachments   Query Analytic   Generate Renderer   Return Updates
